4 kW Danfoss Su Pompası Sürücüsü

Danfoss FC-102 Series AC Inverter for 4kW (5.5HP) 400V 3 Phase Fan or Centrifugal Pump in VxF control to 10A. Converts fixed frequency three phase 400V input to variable frequency three phase 400V to control the speed of a standard AC Induction Motor.Size A2: 90mm Wide x 205mm Deep x 268mm High. IP20.Weight: 4.9kg.Overload: 110% x 60 seconds, 135% x 0.5 seconds.Speed Control Range: 0-590HzBrakin None.Graphical Keypad, 2 Analogue Inputs, 4 Digital Inputs, 1 Analogue Output, 2 Digital Input/Outputs, 2 Relay Contact sets, DC Bus +/- Terminals, Terminals for RS485 Communications.FC Protocol, N2 Metasys, FLN Apogee communication protocols built-in as standard.Programmable from a PC via USB and free Danfoss MCT 10 software.Input Current: 9AInput Voltage: 380-480V Three Phase ±10% at 50-60Hz ±5%EMC Compliance: IEC EN55011 Second Environment Class C3 (Industrial). Can be disabled if required.Wall mount in clean environment or cubicle mount.Rated 45°C Ambient.Ventilation space in front: [not specified], above and below: 100mm, at sides: 0mm.Heat Loss at max output: 124WMounting via 4 x holes at rear on 70mm x 257mm centres.Manufacturer part number is 131B4215.Type code is FC-102P4K0T4E20H2XGXXXXSXXXXAXBXCXXXXDX.
